·Programmable supply priority for PV , battery or Grid
·User-adjustable charge current and voltage
·Wide PV input range (120Vdc -500Vdc),110A MPPT SCC
·Use with lithium batteries
·Working without batteries in sunny day
·WiFi Monitoring Function (optional)
·Anti-dusk kit for harsh environment(optional)
·LCD remote control with 10 meters wire(optional)
·PV and electricity complementary
| Rated Power |
3500VA/3500W |
5500VA/5500W |
| Voltage |
230VAC |
| Selectable Voltage Range |
170-280VAC(for personal computers)
90-280VAC(for home appliances) |
| Frequency Range |
50Hz/60Hz (Auto sensing) |
OUTPUT
| AC Voltage Regulation (Batt.Mode) |
230VAC±5% |
|
| Surge power |
7000VA |
11000VA |
| Efficiency(Peak) |
PV to INV 97% |
| Efficiency(Peak) |
BAT to INV 94% |
| Transfer Time |
10ms (for personal computers)
20ms (for home appliances) |
| Wave form |
Pure Sine Wave |
| INPUTBATTERY & AC CHARGER |
| Battery Voltage |
24VDC |
48VDC |
| Floating Charge Voltage |
27VDC |
54VDC |
| Overcharge Protection |
33VDC |
63VDC |
| Maximum charge current |
80A |
80A |
| MAX.PV Array Power |
5000W |
6000W |
| MPPT Range@ Operating Voltage |
120-500VDC |
| Maximum PV Array Open Circuit Voltage |
500VDC |
| Maximum Charging Current |
110A |
| Maximum Efficiency |
98% |
Dimension.D*W*H
(mm) |
472*297*129 |
| Net Weight (kgs) |
9.5kg |
10.5kg |
| Communication Interface |
RS485/RS232(Standard)
LCD remote/WIFI(Optional) |
| Humidity |
5% to 95% Relative Humidity(Non-condensing) |
| Operating Temperature |
0°C to 55°C
|
| Storage Temperature |
-15°C to 60°C |
